Ergo X Classic Black 3.0x
ERGO X

ERGO X

$2,750.00

A closer view. A more natural posture.
Engineered with a premium prism optical system and a true 69° ergonomic declination angle.
Magnification: 3.0x
Frame Style: Classic
Frame Color: Black

Made to fit you.

  1. Consult
  2. Measure
  3. Order
  4. Create
  5. Deliver

Your custom loupes are crafted to your measurements and delivered approximately 3–4 weeks after your order and measurements are finalized.

Upgrade Your Experience
ERGO X
$2,750.00
$2,750.00
Magnification: 3.0x
Frame Style: Classic
Frame Color: Black
Ergo X Classic Black 3.0x
ERGO X
$2,750.00
Description

Engineered with a premium prism optical system and a true 69° ergonomic declination angle, Ergo X delivers outstanding image clarity, true magnification, and a healthier working posture. Designed for clinicians who demand precision, comfort, and durability, the Ergo X sets a new standard in ergonomic magnification.
Key Benefits

Ergonomic Posture Protection: Utilizes a 69° downward deflection angle, allowing clinicians to maintain a neutral, upright head and neck position to significantly reduce cervical and lumbar fatigue.

Integrated Diopter Fine-Tuning: Built-in diopter compensation allows precise focal adjustments as vision changes over time, extending the usability of the loupes without full optic re-fabrication.

High-Resolution Precision Optics: Delivers crisp, edge-to-edge clarity across multiple magnification levels (3.0x, 4.0x, and 5.5x) with generous depth of field and wide fields of view.

Custom Digital Alignment: Individually tailored based on exact pupillary distance, working distance, and facial geometry for optimal optical convergence.

Featherlight Comfort: Ultra-lightweight optical barrel construction minimizes frame torque and nose-bridge pressure during extended procedures.
What's Included
  • 1x ILLUCO ERGO X Ergonomic Angled Loupes
  • 1x Leather Carrying Case
  • 1x Cleaning Kit (Cloth & Solution)
  • 2x Adjustable Head Straps
  • 1x Silicone U-Shaped Nose Pad
  • 1x Adjustment Screwdriver & Extra Screws

A closer view. A more natural way to work.


Ergo X brings fine details into focus while supporting an upright working posture. Custom-fitted to your measurements, it helps you find a comfortable position and stay focused on the task.

  • Keep Your Head up

    An ergonomic viewing angle lets you look down at your work with less forward head tilt.

  • See clear
    details

    Precision optics bring small details into view for focused, meticulous work.

  • Made
    to Fit You

    Your measurements and working distance guide a fit tailored to the way you practice.

Compare Magnifications

  • 3.0x ERGO X


    Field of View (cm, @45cm):
    10.5


    Depth of Field (cm):
    11

    Resolution (lp/mm):
    28

    Weight w/o frame (g):
    41

  • 4.0x ERGO X


    Field of View (cm, @45cm):
    9


    Depth of Field (cm):
    10

    Resolution (lp/mm):
    34

    Weight w/o frame (g):
    42

  • 5.5x ERGO X


    Field of View (cm, @45cm):
    7.5


    Depth of Field (cm):
    7

    Resolution (lp/mm):
    40

    Weight w/o frame (g):
    61

Complete your setup

Choose an optional headlight and prescription lenses to accompany your custom loupes.

Choose your headlight
Before discounts, shipping and taxes. One of each selected accessory per pair of loupes.

Specifications

Model
IAL-1030
Style
TTL Angled
Magnification
3.0x
Field of view (cm, at 45 cm)
10.5
Depth of field (cm)
11
Working distance (cm)
45~65
Resolution (lp/mm)
28
Weight without frame (g)
41

Frequently Asked Questions

What makes ERGO X different from traditional loupes?

ERGO X’s angled optical design lets you view your working area while keeping your head more upright, supporting a more comfortable working posture.

Which magnification should I choose?

ERGO X comes in 3.0x, 4.0x, and 5.5x. Lower magnification provides a broader view, while higher magnification reveals finer detail. The best choice depends on your procedures and viewing preferences.

Are ERGO X loupes customized to me?

Yes. Your loupes are configured around your measurements and selected options to help align the view with your eyes and preferred working position.

How do I choose my working distance?

Working distance is the distance between your eyes and your treatment area while you’re in a comfortable working posture. Our team can guide you through the measurement process before your order is finalized.

Can I order ERGO X with prescription lenses?

Prescription options are available. Share your current prescription with our team so we can confirm the appropriate configuration for your order.

Can I add a wired or wireless headlight?

Yes. You can pair ERGO X with a wired or wireless headlight to illuminate your working area. Select your preferred option when configuring your setup.

Will I need time to adjust to ergonomic loupes?

You may need an adjustment period, especially if you’re switching from traditional loupes. Start with shorter sessions and adjust your seating and patient position to suit your working distance.

How long will my custom ERGO X loupes take to arrive?

Please allow approximately 3–4 weeks for delivery of your custom loupes. Our team can confirm the estimated timing for your order.
