IDS-3100
Lampe de Wood IDS-3100

Lampe de Wood IDS-3100

$850.00

A Closer Look. More Ways to See.
Bring skin detail into focus with 12x magnification, three lighting modes, and adjustable diopter control. Switch between cross polarization, parallel polarization, and UV illumination to explore different views.
IDS-3100
Lampe de Wood IDS-3100
$850.00
Description

L'IDS-3100 est conçu pour les cliniciens qui ont besoin d'une visualisation diagnostique allant au-delà de la lumière visible. Équipé d'une matrice d'éclairage haute densité de 70 LED (64 LED blanches et 6 LED UV), l'appareil dispose d'un système de lentilles asphériques conçu pour minimiser la distorsion optique périphérique, offrant un grossissement net de 10x sur un champ de vision de 18 mm.

La lampe de Wood permet aux praticiens de basculer entre les modes de polarisation croisée, de polarisation parallèle et d'éclairage UV ciblé (365 nm, 405 nm et combinaison 395+405 nm). Cette polyvalence multispectrale permet une détection précise des affections cutanées superficielles, des dyschromies sous-cutanées et de la fluorescence bactérienne ou fongique sans nécessiter de chambre noire.
Key Benefits

Capacité de diagnostic multi-spectrale :Combine une polarisation en mode double (croisée et parallèle) avec trois modes de longueur d'onde UV ciblés (365 nm, 405 nm, 395+405 nm) pour des évaluations dermatologiques et par fluorescence complètes.

Visualisation améliorée des structures sous-cutanées et infectieuses :Idéal pour évaluer les infections bactériennes (P. acnes), les dermatoses fongiques (Tinea, Malassezia), les troubles pigmentaires (mélasma, vitiligo) et les structures vasculaires superficielles.

Précision optique asphérique :Intègre des optiques asphériques de précision pour éliminer la distorsion périphérique, garantissant une clarté uniforme bord à bord et une présentation réaliste des tissus.

Flux de travail clinique fluide :Équipé d'une base de chargement de bureau pour une accessibilité immédiate et d'une batterie haute capacité de 3 400 mAh pour des examens quotidiens ininterrompus.

Prêt pour la télé-dermatologie :Compatible avec les smartphones pour une documentation photo rapide en haute résolution et une intégration aux dossiers patients numériques.
What's Included
  • Dermatoscope à lampe de Wood IDS-3100
  • Socle de chargement de bureau
  • Câble de chargement USB 5 broches
  • Chiffon de nettoyage pour lentilles optiques
  • Étui de protection en cuir

Explore Beyond White Light.

Expand your view with cross-polarized, parallel-polarized, and UV illumination in one handheld device. The IDS-3100 combines 10x magnification with an aspherical lens system designed to reduce peripheral distortion, helping keep detail clear across the viewing area. Switch between polarized white light and fluorescence observation to explore complementary views of the same skin area.


Clinical Images in Focus

Non-polarized IDS-3100 image of facial acne, showing redness and raised spots across the cheek and chin

IDS-3100 - Acne · Non-Polarized

View the acne-affected cheek and chin under non-polarized illumination, showing raised spots, surface texture, and visible redness. This image provides an overview of how these features are distributed across the facial area. It serves as a reference for comparison with the corresponding polarized view.

Polarized IDS-3100 image of the same acne-affected cheek and chin, showing variations in redness

IDS-3100 - Acne · Polarized

Explore the same acne-affected area under polarized illumination, with visible differences in the appearance of redness and skin coloration. The image offers a complementary view of individual spots and the surrounding skin across the cheek and chin. Compare it with the non-polarized image to see how the lighting setting changes the presentation of these features.

Polarized IDS-3100 view of a documented skin cancer lesion above the upper lip

Lesion Detail Under Polarized Light

View the documented skin cancer lesion under polarized illumination, showing its surface appearance and surrounding skin.

UV IDS-3100 view of the same lesion above the upper lip, showing areas of contrasting fluorescence

IDS-3100 - Skin Cancer · UV

View the same lesion above the upper lip under UV illumination, showing contrasting areas of fluorescence across the examination site. Compared with the polarized image, this view presents a different distribution of visible colors and brightness across the lesion and surrounding skin. The comparison demonstrates changes in appearance under illumination, rather than changes over time.

Specifications

Model
IDS-3100
Polarization
Cross & Parallel & UV
Field of view
100 mm
Magnification
2.5x
Brightness control
3 levels
Smartphone adapter
n/a
LED illumination
64 white LEDs / 6 UV LEDs
Battery
Rechargeable lithium-ion 3,400mAh / 3.7V
Charging time
8.5 hours
Continuous operating time
2.5 ~ 4 hours
Charging method
USB 5pin / Charging Cradle
Dimensions / net weight
141 x 288.5 x 34.5 (mm) / 370g

Frequently Asked Questions

What makes the IDS-3100 different from a white-light dermatoscope?

The IDS-3100 combines cross- and parallel-polarized white light with UV illumination. This gives you additional viewing options for fluorescence observation alongside conventional examination.

What magnification does it offer?

The IDS-3100 provides 10x magnification with an 18 mm field of view for examining skin detail.

Can I switch between polarized lighting and UV illumination?

Yes. You can select cross-polarized, parallel-polarized, or UV illumination to compare the appearance of the same area under different lighting conditions.

What is the benefit of its aspherical lens system?

The aspherical optics are designed to reduce peripheral distortion, helping maintain a clear view toward the edges of the image.

Does the IDS-3100 have an adjustable focusing dial?

No. The IDS-3100 does not include a focusing dial. If adjustable focus is a priority, consider a model with that feature, such as the IDS-9100, IDS-1100, or IDS-1100C.

Is the IDS-3100 rechargeable?

Yes. It uses a rechargeable lithium-ion battery and includes a desktop charging cradle for convenient charging between examinations.

Can I capture images with my smartphone?

Yes. Smartphone imaging is supported with a compatible phone attachment, sold separately. Contact us for help selecting the correct adapter for your device and phone.

What is the difference between cross- and parallel-polarized lighting?

Cross-polarized lighting reduces surface reflections to help reveal detail beneath the skin’s surface. Parallel-polarized lighting provides a complementary view of surface features. Switching between them lets you examine the same area from different perspectives.
